IMA30F25 MStar335+SC3335

3MP AI Hunman Detection HD Network Camera Module

● 1/2.7” Low-illumination Progressive Scan CMOS Sensor;

● 3.0MP HD resolution;

● Embedded Web Server, support Internet Explore monitoring, configuration, upgrade;

● Support All subnet ONVIF,Easy connect different network segments NVR;

● Support Danale APP on Android, IOS by P2P;

● Support ONVIF2.6;

● H.265+/H.265/H.264 main profile encoding, two simultaneous video streams ;

● Support smart dual light, infrared, warm light full color three modes optional;

● Support AI human detection,Area detection;

● Standard SDK(Linux,Windows)，easily to be integrated with other digital systems.

Models		IMA30F25
		3.0MP AI Hunman Detection HD Network Camera Module
Image Sensor		1/2.7” 3.0MP CMOS SC 3335
Min. Illumination		Color：0.01Lux
S/N Ratio		≥38dB
Digital noise Reduction		DNR,3DNR
Exposure Mode		Auto/Manual/shutter mode（shutter range variable）
White Balance		Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
Day & Night		Day / Night / External control（IR Cut Filter）
Video Compression		H.265+/H.265/H.264 Main Profile
Audio Compression		G711U/G711A/AAC
Max. Image Resolution		3MP@25fps
Image Resolution	Main stream	3MP@25fps,1080P/720P/D1@30pfs
	Sub-stream	D1/VGA/640*360/CIF@30fps
Streams		Dual streams
Bitrate		CBR/VBR bitrate：50Kbps~6Mbps variable
Simultaneous Live View		Main stream Up to 5,Sub-stream Up to 5
OSD		Support camera name,time display ,etc,OSD position can be adjusted
Motion detect		Support
P2P		Android,IOS
Protocols		HTTP/NTP/DHCP//RTSP/P2P/ONVIF,GB28181/RTMP(optional)
Onvif		Onvif 2.6
Network		10/100M Base-TX Ethernet, RJ45 Connector
Store		Unspport
Protection Level		TVS 6,000V lightning protection
Power Supply		12VDC/POE
Dimensions		38x38mm
Working Temperature		-30°C ~85°C, Humidity≤90%RH(Unsupport-condensing)
